Thumpstar - ATV 140cc Quad Bike
Thumpstar - ATV 140cc Quad Bike
Couldn't load pickup availability
Throttle Limiter
Parental control is a must on any ATV where a child is just starting out and learning how to ride. We here at Thumpstar have tailored the ATV125 to those junior riders who are learning, and given you the parent or teacher full control over your child's bike, with an easily adjustable throttle limiter, the speed and power delivery can be easily limited.
Lanyard
Safety is an important feature for kids just starting out and parents who are supervising. The ATV125 comes equipped with an emergency lanyard which can be attached to your child, or be held by you at a short distance, and will instantly kill the bike should it be pulled off.
Rear disc brakes
Something more important than the power to go fast is stopping power. The ATV125 is well suited for this, with rear disc brakes it has more than enough stopping power to go from fast to stopped in the blink of an eye.
4 gears with reverse
Where young riders are still coming to grips with how to handle a motorcycle not having to worry about to many features is important. The ATV125 has a centrifugal clutch which allows the beginner rider to learn throttle control, braking, and balance without having to simultaneously learn how to deal with a clutch.
Steel footrest
Ergonomically designed steel footrests not only look sleek on these bikes, but also provide the rider with unparalleled grip and comfort while remaining a heavy duty alternative to the cheap plastic often found with our competitors.
Mikuni Carb
Reliability comes with using trusted brands of parts. The ATV125 now includes a Mikuni VM22 carburetor which allows us to faithfully say that the performance and reliability of these bikes has been greatly improved on previous models.
Product Packaging
Specifications
| ENGINE & TRANSMISSION | |
| Engine | Zongshen | 4 Stroke |
| CC Rating | 140cc |
| Gearbox | Semi Auto | 3 speed and Reverse (RN123) |
| Starter | Electric Start |
| Carburetion | Molkt 19mm |
| Exhaust | Standard | 28mm Exhaust System |
| Final Drive | 428 Chain |
| Top Speed | 70kph(depending on gearing) |
| SUSPENSION, BRAKES, & WHEELS | |
| Suspension Front | Double A-Arm | Dual Shock Length 320mm |
| Suspension Rear | Mono shock | 270mm |
| Brakes Front | Drum |
| Brakes Rear | Disc | Single Piston | Dual Park Brake |
| Wheel & Tire Front | Steel Rim | Tubeless | 19x7.00 - 8" |
| Wheel & Tire Rear | Steel Rim | Tubeless | 18x9.50 - 8" |
| Max Load | 80 kgs |
| DIMENSIONS & WEIGHT | |
| Wheelbase (axle to axle) | 1000mm | 39" |
| Seat Height | 700mm | 28" |
| Product Weight N.W | G.W | 105/120kg | 231/264 |
| Tank Capacity | 4.3 Litres | 1.1gallon |
| Product Packing Size | 1200×760×640mm | .60m3 |
